This subreddit encourages questions, constructive feedback, and the sharing of knowledge and resources among IB students, alumni, and teachers. The free body diagram and coordinate frame for this system can be drawn as shown below.This subreddit is for all things concerning the International Baccalaureate, an academic credential accorded to secondary students from around the world after two vigorous years of study, culminating in challenging exams. The figure below shows an example of two bodies in contact, with gravity acting downwards and constraints given as shown.

For example, see physics of a golf swing and trebuchet physics. You do this by setting up kinematics equations that capture every stage of the motion.

It’s a good idea to keep the free body diagram as general as possible for those cases where you need to solve for the (changing) position of the bodies over time, and (consequently) the changing values of the forces, velocity, and acceleration of the bodies over time.

This choice often depends on the desired accuracy of the solution and the required effort and time spent to arrive at the solution.

A decision must be made whether the problem can be modeled in one-dimension, two-dimensions, or three-dimensions.

On the other hand, if you get negative values for the forces and/or moments, this means that they are acting in the opposite direction that you assumed in your free-body diagram.

A homogeneous bar (mass mi, length, negligible thickness) is jammed between the wall at point A and a homogeneous cylinder (mass M. Enter the number representing the correct part of the free body diagram for points A,B,C and D. When you solve the equations of motion for a particular problem and you get positive values for the forces and/or moments, this means that they are acting in the direction you assumed, in your free body diagram. 5 Problem 2) Friction (1/3) 2a) Draw the free body diagram for this problem. Make sure you are consistent with the sign convention used. If the forces and/or moments acting on the bodies are unknown, assign them directions of your choosing.When drawing the forces acting on pairs of bodies in contact with each other, apply Newton's Third Law. This allows for the physical interaction between the bodies to be established, thus allowing the whole system to be solved simultaneously. Sometimes there are multiple bodies interacting with one another, so a free-body diagram must be drawn for each body.For example, a constant friction coefficient can be assumed for determining the friction force acting on a body in contact with a rough surface. Make any necessary assumptions in order to simplify the solution.In order to accurately relate the forces acting on a body to its acceleration, the coordinate system used must be an inertial reference frame. The choice of coordinate system, such as Cartesian, or polar is often based on convenience.

Assign a coordinate system, in order to solve for the different unknowns in terms of coordinate values.

Body forces (such as gravity) are replaced with equivalent forces passing through the center of mass.

Account for any constraints, which restrict the motion of the body in some way (e.g.

Replace all contact locations with other objects, or supports, with equivalent resultant force and/or moment vectors acting at those locations.

The following general procedure is used when drawing a free body diagram: It is especially important for more complicated problems where it is easy to accidentally forget something if you’re trying to solve the problem just by directly plugging values into equations, without using a visual aid first. It allows you to get a “feel” for what’s going on before applying the equations of motion. The free body diagram allows you to set up the problem properly so that you can correctly solve for unknowns such as forces, and acceleration. The purpose of a free body diagram is to show all the forces acting on a body due to contact with other objects, and/or due to body forces acting on the body (such as gravity or magnetic fields). The free body diagram is a pictorial representation used to analyze the forces acting on a body.
